Why it is slow in P6
P6 flags driving relationships and can show the longest path, but answering "why is this milestone on that date?" still means tracing predecessors level by level with Trace Logic, checking each link's lag on the right calendar, and noticing when an SS or FF link, a constraint or an actual date takes over. On a path of twenty activities that is half an hour of clicking, and easy to get wrong.
What the server computes
p6_driving_path works backward from the target on the early dates of the last F9. A link drives when its gap is zero (within 5 minutes): the predecessor's date plus the lag, counted on the calendar your project's lag option names, reaches the successor's date. It follows every driving predecessor, level by level, and stops at the root of each chain, with its type:
- data date: an in-progress or open activity whose remaining work starts at the data date;
- constraint: an early constraint (start on or after, and the like) sets the date;
- actual date or completed predecessor: progress already recorded;
- open start: no predecessor drives it, the logic is missing;
- unexplained: nothing in the network explains the date; worth a look in P6.
Ask for the driving path
What drives MS-1100 - Project completion in DEMO-SS225? Show the driving path root first, with dates and total float.
The assistant calls p6_driving_path(project="DEMO-SS225", target="MS-1100"). On the demo project the path has 24 activities over 17 levels. An excerpt, root first:
| Activity | Early start | Early finish | Drives through |
|---|---|---|---|
| PRC-TR-1040 - Power transformers 225/63 kV - manufacturing | 26 Oct 2026 | 2 Apr 2027 | FS (root: data date) |
| PRC-TR-1050 - Power transformers 225/63 kV - factory acceptance test | 5 Apr 2027 | 9 Apr 2027 | FS |
| PRC-TR-1060 - Power transformers 225/63 kV - shipping and delivery to site | 12 Apr 2027 | 1 Jun 2027 | FS |
| MS-1040 - Power transformers delivered to site | 1 Jun 2027 | 1 Jun 2027 | FS |
| CON-HV-1040 - Power transformer TR1 installation and oil filling | 2 Jun 2027 | 29 Jun 2027 | SS 10 d |
| CON-HV-1050 - Power transformer TR2 installation and oil filling | 16 Jun 2027 | 13 Jul 2027 | FS |
| COM-ENR-1050 - Trial operation | 1 Sep 2027 | 28 Sep 2027 | FS |
| MS-1100 - Project completion | 5 Oct 2027 | 5 Oct 2027 | target |
The answer to "why 5 October 2027?" is therefore the transformer manufacturing still in progress: its remaining work starts at the data date and nothing earlier in the network can pull the chain forward. Note the SS 10 d link between the two transformer installations: a lag that a manual trace can easily read on the wrong calendar.
Useful variations:
- "Trace only 5 levels" sets
max_depth=5. - "Include completed activities" adds the completed part of the path, which P6 also places under retained logic.
- "Is the driving path the same as P6's float path 1?" compares with
p6_float_paths, when the project was scheduled with multiple float paths.
Where the float comes from
The driving path explains the early dates. The total float comes from the late dates, which are set by the successors and finally by a constraint or the project's must finish by date.
Why does MS-1100 - Project completion have -36 days of total float?
p6_float_origin(project="DEMO-SS225", task_code="MS-1100") answers that the float comes from the project must finish by date, 16 August 2027: the late finish is pinned there while the early finish is 5 October 2027, 36 working days later. For an activity in the middle of the network, it walks forward along the successor links that set its late dates and names the source: a constraint, the must finish by date, or an open end.
When the source is the must finish by date, removing a constraint on an activity will not help: only a shorter driving path, or a later must finish by date agreed with the client, changes it. That distinction matters in a delay discussion.
Test a change on the driver
What if PRC-TR-1040 - Power transformers manufacturing finishes 15 working days earlier? Show the new project finish and the milestones that move.
p6_schedule_whatif applies the change in memory, runs the server's CPM engine and compares the result with P6's last F9: project finish before and after, milestones, and the activities that become or stop being critical. Nothing is written to the database. Before relying on it, p6_cpm_validate shows how closely the engine reproduces P6's dates on your project.
Setup in Claude
- Install the server: the installer registers it with Claude Desktop and Claude Code (install steps).
- In the Settings window, choose the Full tool profile: the driving path and float origin tools are not in the Basic set.
- Press F9 in P6, then restart Claude and ask the questions above with your own Project ID and Activity IDs.
The same prompts work in Cursor, VS Code and any MCP client: the server does the tracing, the model writes the explanation.
